Carbon Round Adjustable Die, #6-32 UNC, 13/16 in OD

Greenfield Threading Carbon Round Adjustable Dies

Description

  • Use in hand-held die stocks or machine holders
  • Chamfered on both faces, 2 to 3 threads on one side and 1 to 2-1/2 threads on the other for threading close to the shoulder
  • Beveled screw slot to remove screw when die is used in a machine holder

Specification

Applicable Materials

All Metals

Cutting Direction

Right

Outside Diam [Nom]

0.8125 in

Material

Carbon Steel

Thread Size [Nom]

#6

Threads Per Inch [Nom]

32

Shank Size Symbol

#6-32 UNC

Style

Round Adjustable Die

Thread Standard

0.138 in

Type

Die

Brand
